    Single Layer Flex Pcb Stackup Manufacturing Process Single Sided Board

    Ask Lasest Price
    Brand Name : kerongda
    Model Number : KRD-PCB-S04
    Certification : CE
    Price : USD0.01~0.1/dot
    Payment Terms : L/C, T/T
    Supply Ability : 40000dot/h
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    Single Layer Flex Pcb Stackup Manufacturing Process Single Sided Board

    Pcb/Single-Sided pcb/Fr-4/Cem/Pcba/Smt

    Single-Sided pcb Smt


    SMT basic process elements include: screen printing (or dispensing), mounting (curing), reflow soldering, cleaning, testing, repair

    1. Screen printing: Its function is to leak solder paste or patch glue onto the PCB pad to prepare for the welding of components. The equipment used is screen printing machine (screen printing machine), located at the front end of the SMT line.

    2, dispensing: it is to drop the glue to the fixed position of the PCB board, its main role is to fix the components to the PCB board. The equipment used is the dispensing machine, which is located at the front end of the SMT production line or behind the testing equipment.

    3. Mounting: Its function is to accurately install the surface assembly components to the fixed position of PCB. The equipment used is the SMT machine, which is located behind the screen printing machine in the SMT production line.

    4, curing: its role is to melt the patch glue, so that the surface assembly components and PCB board firmly bonded together. The equipment used is the curing furnace, which is located behind the SMT machine in the SMT line.


    Our Advantages:

    1. Program and functional test and package by Free.

    2. High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% functional test.

    3. Professional service: PCB/FPC/Aluminium Making, SMT, DIP, Component Sourcing, OEM with 21 years experience.

    4. Certifications: UL, 94v-0, CE, SGS, FCC, RoHS, ISO9001, ISO14001,IATF16949


    Single Layer Flex Pcb Stackup Manufacturing Process Single Sided BoardSingle Layer Flex Pcb Stackup Manufacturing Process Single Sided BoardSingle Layer Flex Pcb Stackup Manufacturing Process Single Sided BoardSingle Layer Flex Pcb Stackup Manufacturing Process Single Sided Board


    Kerongda is a PCB manufacturer, providing turnkey and partial turnkey printed circuit board assembly services.We can produce customized PCB board and PCBA for you ,PCB solder mask color ,material, thickness etc... all can be chosed as your demands.
